Pivot-Top jack stand post

Pivot-Top™ Posts for ESCO Jack Stands

The factory ESCO  jack stands have a large 4.25" diameter rubber padded flat top that won't damage the jack points on your high end luxury car. In addition to the rubber padded posts, Reverse Logic offers a custom Pivot-Top™ post with a pivoting block which fits the jack points on BMW, Mercedes-Benz, and Nissan GT-R chassis.

The posts can be used with ESCO 10498 or 10499 jack stands. Since the jack stands are positioned inside the vehicle jack pocket, they will be in the ideal location for supporting the weight of the car and won’t damage the jack points.

ALWAYS USE JACK STANDS IN PAIRS. DO NOT SUPPORT YOUR CAR WITH ONE, THREE, OR FOUR JACK STANDS. USE WHEEL CHOCKS IN FRONT AND BEHIND THE WHEELS ON THE GROUND.

Reverse Logic also offers blocks for Torin T43004 aluminum jack stands which will fit into the plastic jack points on late model BMW, MINI, Mercedes-Benz, and Nissan GT-R chassis. It is necessary to drill a 10mm hole in the Torin jack stand saddle to use the blocks.

ESCO 10499 Jack Stands - 11" to 17"

SKU E-10499
$131.90
In stock
1
Product Details
  • Removable Rubber Flat Top
  • 7 Adjustable Positions (5 w/Pivot-Top™ post)
  • Circular Base Pads for Maximum Stability
  • Sold in pairs


NOW IN STOCK!

ESCO 10499 jack stands are smaller versions of the highly regarded ESCO 10498 which are known for their sturdy design and flat top rubber padded saddle. The 10499 stands have a minimum height of about 11" and a maximum height of about 17" with the flat top posts. The tripod legs are about 10" apart on the 10499 model. There are 4 holes in the solid steel post which are spaced about 50mm apart. The 10499 stands have two holes in the outer steel tube so the post can be positioned at 7 different heights.


The ESCO 10499 stands are also available with a custom stainless steel Pivot-Top™ post with a pivoting block or a pivoting 63mm diameter pad. The 52mm by 30mm x 28mm block fits the jack points on BMW/MINI, Nissan GT-R, and Mercedes-Benz chassis jack points. The range of the 10499 stand with the custom post is 11" to 15". The Pivot-Top™ posts are also available separately to customers who already own a set of ESCO jack stands.


The 10499 stands are designed for cars which have low ground clearance and jack points between the front and rear axles.
